| Display |
| Size |
28” |
| Resolution |
3840×2160 |
| Brightness |
300cd/m² |
| Aspect ratio |
16:9 |
| Contrast |
1000:1 |
| Viewing Angle |
170°/160°(H/V) |
| HDR |
HDR 10 （under HDMI model） |
| Supported Log formats |
Sony SLog / SLog2 / SLog3… |
| Look up table (LUT) support |
3D LUT (.cube format) |
| Technology |
Calibration to Rec.709 with optional calibration unit |
| Video Input |
| SDI |
1×3G |
| HDMI |
1×HDMI 2.0, 3xHDMI 1.4 |
| DVI |
1 |
| VGA |
1 |
| Video Loop Output |
| SDI |
1×3G |
| Supported In / Out Formats |
| SDI |
720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60 |
| HDMI |
720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
| Audio In/Out (48kHz PCM Audio) |
| SDI |
12ch 48kHz 24-bit |
| HDMI |
2ch 24-bit |
| Ear Jack |
3.5mm |
| Built-in Speakers |
2 |
| Power |
| Operating power |
≤61.5W |
| DC In |
DC 12-24V |
| Compatible batteries |
V-Lock or Anton Bauer Mount |
| Input voltage (battery) |
14.4V nominal |
| Environment |
| Operating Temperature |
0℃~50℃ |
| Storage Temperature |
-20℃~60℃ |
| Other |
| Dimension(LWD) |
670×425×45mm / 761×474×173mm (with case) |
| Weight |
9.4kg / 21kg (with case) |
