| Display |
| Size |
12.5” |
| Resolution |
3840×2160 |
| Brightness |
400cd/m² |
| Aspect ratio |
16:9 |
| Contrast |
1500:1 |
| Viewing Angle |
170°/170°(H/V) |
| Video Input |
| SDI |
1×3G |
| HDMI |
1×HDMI 2.0, 3xHDMI 1.4 |
| Display-port |
1×DP 1.2 |
| Video Loop Output |
| SDI |
1×3G |
| Supported In / Out Formats |
| SDI |
720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60 |
| HDMI |
720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
| Display-port |
720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30/50/60 |
| Audio In/Out (48kHz PCM Audio) |
| SDI |
12ch 48kHz 24-bit |
| HDMI |
2ch 24-bit |
| Ear Jack |
3.5mm |
| Built-in Speakers |
1 |
| Power |
| Operating power |
≤16.8W |
| DC In |
DC 7-20V |
| Compatible batteries |
NP-F Series |
| Input voltage (battery) |
7.2V nominal |
| Environment |
| Operating Temperature |
0℃~60℃ |
| Storage Temperature |
-20℃~60℃ |
| Other |
| Dimension(LWD) |
297.6×195×21.8mm |
| Weight |
960g |
